Head Temperature transmitte TMT192B

Release date:2018-08-20 14:46:50

Say it, and it will wake you up, show you music, tell your baby stories, wake you up, and choose the quickest way to get to the company. It can even control smart devices in the home. Not only that, you can train it, make it smarter and better understand you.

1)Galvanic isolation 2000VAC
2)Operation: HART-protocol
3)PC programmable temperature transmitter for converting various input signals into a scalable 4 to 20mA analogue output signal
4)Wide voltage supply range
5)Expanded resistance input (max 2kΩ)
6)Expanded voltage input (max 2KmV)

* Internal cold junction
* Fault signal on sensor break or short circuit
* 2-wire technology, 4 to 20mA analogue output
* High accuracy in total ambient temperature range
* Customer specific measurement range setting or expanded SETUP

Technical data:
Output:  4 to 20mA
Supply voltage:7.5 to 45VDC
Input:RTD, TC, Ohm, mV
Influence of ambient:Negligible
Load influence:Negligible
Power supply influence:Negligible
Installation:sensor head Form B
