Head Temperature transmitter TMT190B

Release date:2018-08-22 10:14:09

Life is a playground. We should all go for it. Park Kingfisher Crow, playground breeze brush face ... don't wait, let 9 balance car become your wings, now go! Climbing on it immediately feels the magic of technology, it can automatically help you balance, an idea the body can lean forward a little bit. High-performance, advanced control algorithms, numerous sensors and high-performance processors make it flexible and easy to drive, easy to cope with common road conditions, up to 22km[ 1] The distance you can drive will make you have a good time. Car with the control of the heart, flying general sense of speed, all these wonderful feelings, so you look forward to the next departure.




Specifications:
1)PC programmable temperature transmitter for converting various input signals into a scalable 4 to 20mA analogue output signal
2)Wide voltage supply range
3)Expanded resistance input (max 2kΩ;)
4)Expanded voltage input (max 2KmV)

Performance:
* e-HART communication
* Internal cold junction
* Fault signal on sensor break or short circuit
* 2-wire technology, 4 to 20mA analogue output
* High accuracy in total ambient temperature range
* Customer specific measurement range setting or expanded SETUP


Technical data:
Output:  4 to 20mA
Supply voltage:7.5 to 45VDC
Input:RTD, TC, Ohm, mV
Influence of ambient:Negligible
Load influence:Negligible
Power supply influence:Negligible
Resolution:0.3uA
Installation:sensor head Form B
Operation:PC-programmable
